GEAR MOTOR 9.5CC CYLINDRICAL Ø16/9" SHAFT SAE-A FLANGE
Hydrokit Part Number : M109D6ZA
Technical information
PARKER GEAR MOTOR
- Direction of rotation: Bidirectional
- Displacement, 9.5cc
- Flange: SAE A
- Shaft: Cylindrical, Ø9/16", parallel key
- Ports: SAE 10 side rear
- Max. speed of rotation: 5,000rpm
- Max. pressure: 103bar
- Geniune Parker reference: MGG20025 BC1A3
- Direction of rotation: Bidirectional
- Displacement, 9.5cc
- Flange: SAE A
- Shaft: Cylindrical, Ø9/16", parallel key
- Ports: SAE 10 side rear
- Max. speed of rotation: 5,000rpm
- Max. pressure: 103bar
- Geniune Parker reference: MGG20025 BC1A3
