FILTRE PRESSION 280L/MIN 10µm
Hydrokit Part Number : FPL28010AA
Technical information
PRESSURE FILTER
- Ports: 1" BSP
- Flow rate: 150lpm (Delta P=0.75bar)
- Max. working pressure: 420bar
- Cartridge 10µm absolute (Beta>200)
- Bypass valve calibrated to at 6bar
- Predisposed for clogging indicator
- Ports: 1" BSP
- Flow rate: 150lpm (Delta P=0.75bar)
- Max. working pressure: 420bar
- Cartridge 10µm absolute (Beta>200)
- Bypass valve calibrated to at 6bar
- Predisposed for clogging indicator
Technical data
| Type of product | Filtre en ligne bi-directionnel | ||
| Débit maxi | 280 | l/min | |
| Max working pressure | 420 | bar | |
| Implantation | G1'1/4 | ||
| Degré de filtration | 10 | Micron | |
| Média Filtrant | Microfibre de plastique | ||
| Option | Indicateur colmatage visuel |
